Night Vision Thermal Scope TS384-15

The multi-function fusion binocular processes the images of infrared thermal imaging, laser ranging and low-light sensors through algorithms, and combines the images of the three in a certain proportion to highlight the hot targets. By observing the merged image, the user can not only see the hot target, but also the outline of the environment background, and can quickly and accurately obtain the observation target.


Specifications of Rifle Scope TS384-15


Surface treatmentAnticorrosion coating
MaterialAircraft grad aluminum
Detector384x288
Sensor typeVOX
Pitch17um
Frame rate50Hz
Zoom1x,2x
Field of view15.5°×12.4°
PolarityWhite hot ,black hot,speia,red hot, green hot
ReticleYES
BrightnessAuto/manual
ContrastAuto/manual
DDE technology for contrast0~31
CompassAzimuth accuracy 1°
Angle of pitch accuracy 10
Video storageIn-built 16G, for 4hours video or 20000images
Display typeColor OLED,0.6inch
Pupil Distance30mm
Diopter±5SD
NETD≤35mk(normal temperature)
BatteryCR123A(4 pcs),18650(2 pcs),≥7H
Interface9-pin LEMO interface Power, video, rs232, USB
Working temperature-40°~50°
Storage temperature-50°~60°
